Elara Crestron DM Lite HD-TX-4KZ-111-1G-W

Overview

Range/Series Overview

IMPORTANT: This Range/Series overview section describes the range of which this product belongs. Features of different versions might be mentioned and may not apply to the specific product on this page. Please view Specs for specification of product.The HD-TX-4KZ-111-1G is a DM Lite 4K60 4:4:4 wall plate transmitter designed to interoperate with a DM Lite receiver or DMPS Lite switcher. The HD-TX-4KZ-111-1G includes a USB-C input with DisplayPort Alt Mode capability, enabling the transmission of a DisplayPort AV signal. A CAT5e or higher twisted pair cable is used to connect the HD-TX-4KZ-111-1G to the DM Lite receiver or DMPS Lite switcher. For 1080p, WUXGA, and 2K signals, a cable length of up to 230 ft (70 m) is supported. For UHD and 4K signals, a cable length of up to 130 ft (40 m) is supported.

Features Summary

• Interoperability with a DM Lite receiver or DMPS Lite switcherThe DM Lite output port of the HD-TX-4KZ-111-1G must be connected to a DM Lite input port of a DM Lite receiver or DMPS Lite switcher.
• 4K60 4:4:4 and HDR supportThe HD-TX-4KZ-111-1G supports video resolutions up to 4K60 with 4:4:4 color sampling. HDR10, HDR10+, and Dolby Vision video formats are also supported.
• One-gang wall plate designThe HD-TX-4KZ-111-1G can receive power from the remote DM Lite receiver (surface mountable only) or DMPS Lite switcher.
